Description
HF2417 Ride On Mower
A versatile lawn tractor suitable for lawns up to 6,000m2. The HF2417 has a generous 102cm cutting deck and has been developed with enhanced convenience and comfort in mind. The latest innovations include a Euro 5 compliant engine, full colour LCD display, a Speed Hold System and USB charging.
Product Overview:
- Cutter Deck Size: 102cm
- Garden Size: Very Large. Suitable for lawns up to 6,000m² (1.5 acres)
- Transmission: Variable Hydrostatic Drive - This lawnmower's speed is adjusted by pedal control
- Mulching: Versamow Selective - You can chose whether you want to collect the grass cuttings into the bag or finely shred them onto the lawn
- Grass Bag Capacity: 300L
- Grass Bag Dumping: Manual - Dispose of grass clippings by lifting a lever
- Soft Grip Steering and Colour LDC Display: Yes
- Speed Hold: Yes - You are able hold your speed at 4 intervals (2/3/5/6km/h)
- USB Charging and Device Holder: Yes
ENGINE:
Power is by Honda’s smooth and powerful GCV530 V-twin motor. This offers great fuel consumption with low emissions, low vibration, and long operational life span.
DRIVE:
A smooth foot operated Hydrostatic transmission means both of the operators hands are on the steering wheel rather than one on a hand controller. This allows more control making it safer for the operator.
DASH:
All of the mowers vital systems are clearly shown at a glance thanks to LED technology. Everything from low fuel level, battery voltage and blade engagement are shown. There is also an audible alarm to notify the operator when the catcher is full.
SAFETY:
The unit has many safety cut outs to protect the user. A button allows the user to reverse with the blades in operation. Automatic headlights increase the visual safety of the mower and improves visibility in low light conditions.
Function
| Blade brake clutch | Electromagnetic |
| Optiflow | Yes |
| Grass bag dumping | Manual |
| Positions and cutting | 7 |
| Noise value - sound power level (dB(A)) | 100 |
| Mulching | Versamow™ selective mulching |
| Rear deflector | Optional |
| Tow hitch | Optional |
Dimensions
| Length (mm) | 2445 |
| Width (mm) | 1060 |
| Height (mm) | 1230 |
| Dry weight (kg) | 239 |
Cutting
| Cutter deck size (cm) | 102 |
| Number of blades | 2 |
| Synchro or Asynchro | Synchro |
| height adjustment (mm) | 29-90 |
| Grass bag capacity (Litres) | 300 |
Engine
| Engine | 4-stroke OHC V-twin |
| Engine displacement (cc) | 530 |
| Engine model | GCV530 |
| Engine Rated Power (kW/rpm) | 9.4/2,800 |
| Fuel tank capacity (Litres) | 8.5 |
| Engine oil capacity (Litres) | 1.3 |
| Transmission type | Variable: Hydrostatic |
| Driving speed (km/h) | Progressive 0 to 8.2 |
Tyres
| Front tyres (diameter x width - rim) (inches) | 15 x 6.00 - 6 |
| Rear tyres (diameter x width - rim) (inches) | 18 x 8.50 - 8 |
| Turning radius (m) | 1.8 |
